Ġewż Hex Stainless Steel
Standard: ISO 4032
Tip ta' Thread: Thread oħxon
Komodità: Ġewż Hex Stainless Steel
Imsemmi wkoll: Ġewż Hex SS
Materjal: Stainless steel
Klassi tal-Proprjetà:A2(50-80), A4(50-80)
Dijametru: 0#, 1#, 2#, 3#, 4#, 5#, 6#, 8#, 10#, 12#, 1/4, 5/16, 3/8
Temm: Sempliċi, Passivat, Personalizzazzjoni
Tip ta 'sewqan: Hex Estern
Standard Alternattiv: DIN 970, DIN 555, ISO 4033, ISO 4034, ASME B 18.2.2MOQ: 1000kgs
Lead Time: 30 sa 60 jum
Introduzzjoni tal-Prodott
Bħala fornitur globali ta 'soluzzjonijiet ta' rbit personalizzati, il-proċess ta 'servizz ta' AYA huwa wkoll qrib il-klijenti daqs il-prodotti ta 'AYA. Minn tiddeskrivi l-ħtiġijiet għal servizzi ta 'segwitu, AYA se fil-pront u ma tagħmilx sforz biex tgħin lill-klijenti jsolvu kwalunkwe problemi ta' qfil li jinqalgħu, biex jeliminaw it-tħassib tal-klijenti.
DESKRIZZJONI TAL-PRODOTT
| Isem tal-Prodott | Ġewż Hex Stainless Steel |
| Imsemmi wkoll | Ġewż Hex SS |
| Materjal | Azzar li ma jsaddadx |
| Standard | ISO 4032 |
| Klassi tal-Proprjetà | A2(50-80), A4(50-80) |
Dijametru | 0#, 1#, 2#, 3#, 4#, 5#, 6#, 8#, 10#, 12#, 1/4, 5/16, 3/8 |
| Temm | Plain, Passivated, Customization |
| Tip tas-sewqan | Hex Esterni |
| Tip ta' Thread | Ħajt oħxon |
| Standard Alternattiv | DIN 970,DIN 555,ISO 4033,ISO 4034,ASME B 18.2.2 |
TABELLA TA’ DIMENSJONIJIET
| Daqs tal-ħajt | M1.6 | M2 | M2.5 | M3 | M4 | M5 | M6 | M8 | M10 | M12 | M16 | M20 | M24 | M30 | M36 | |
| D | ||||||||||||||||
| P | Żift | 0.35 | 0.4 | 0.45 | 0.5 | 0.7 | 0.8 | 1 | 1.25 | 1.5 | 1.75 | 2 | 2.5 | 3 | 3.5 | 4 |
| c | max | 0.2 | 0.2 | 0.3 | 0.4 | 0.4 | 0.5 | 0.5 | 0.6 | 0.6 | 0.6 | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 |
| min | 0.1 | 0.1 | 0.1 | 0.15 | 0.15 | 0.15 | 0.15 | 0.15 | 0.15 | 0.15 | 0.2 | 0.2 | 0.2 | 0.2 | 0.2 | |
| da | max | 1.84 | 2.3 | 2.9 | 3.45 | 4.6 | 5.75 | 6.75 | 8.75 | 10.8 | 13 | 17.3 | 21.6 | 25.9 | 32.4 | 38.9 |
| min | 1.6 | 2 | 2.5 | 3 | 4 | 5 | 6 | 8 | 10 | 12 | 16 | 20 | 24 | 30 | 36 | |
| dw | min | 2.4 | 3.1 | 4.1 | 4.6 | 5.9 | 6.9 | 8.9 | 11.6 | 14.6 | 16.6 | 22.5 | 27.7 | 33.3 | 42.8 | 51.1 |
| e | min | 3.41 | 4.32 | 5.45 | 6.01 | 7.66 | 8.79 | 11.05 | 14.38 | 17.77 | 20.03 | 26.75 | 32.95 | 39.55 | 50.85 | 60.79 |
| m | max | 1.3 | 1.6 | 2 | 2.4 | 3.2 | 4.7 | 5.2 | 6.8 | 8.4 | 10.8 | 14.8 | 18 | 21.5 | 25.6 | 31 |
| min | 1.05 | 1.35 | 1.75 | 2.15 | 2.9 | 4.4 | 4.9 | 6.44 | 8.04 | 10.37 | 14.1 | 16.9 | 20.2 | 24.3 | 29.4 | |
| mw | min | 0.8 | 1.1 | 1.4 | 1.7 | 2.3 | 3.5 | 3.9 | 5.2 | 6.4 | 8.3 | 11.3 | 13.5 | 16.2 | 19.4 | 23.5 |
| s | daqs=nominali massimu | 3.2 | 4 | 5 | 5.5 | 7 | 8 | 10 | 13 | 16 | 18 | 24 | 30 | 36 | 46 | 55 |
| min | 3.02 | 3.82 | 4.82 | 5.32 | 6.78 | 7.78 | 9.78 | 12.73 | 15.73 | 17.73 | 23.67 | 29.16 | 35 | 45 | 53.8 | |
| Daqs tal-ħajt | M42 | M48 | M56 | M64 | (M3.5) | (M14) | (M18) | (M22) | (M27) | (M33) | (M39) | (M45) | (M52) | (M60) | ||
| D | ||||||||||||||||
| P | Żift | 4.5 | 5 | 5.5 | 6 | 0.6 | 2 | 2.5 | 2.5 | 3 | 3.5 | 4 | 4.5 | 5 | 5.5 | |
| c | max | 1 | 1 | 1 | 1 | 0.4 | 0.6 | 0.8 | 0.8 | 0.8 | 0.8 | 1 | 1 | 1 | 1 | |
| min | 0.3 | 0.3 | 0.3 | 0.3 | 0.15 | 0.15 | 0.2 | 0.2 | 0.2 | 0.2 | 0.3 | 0.3 | 0.3 | 0.3 | ||
| da | max | 45.4 | 51.8 | 60.5 | 69.1 | 4 | 15.1 | 19.5 | 23.7 | 29.1 | 35.6 | 42.1 | 48.6 | 56.2 | 64.8 | |
| min | 42 | 48 | 56 | 64 | 3.5 | 14 | 18 | 22 | 27 | 33 | 39 | 45 | 52 | 60 | ||
| dw | min | 60 | 69.5 | 78.7 | 88.2 | 5 | 19.6 | 24.9 | 31.4 | 38 | 46.6 | 55.9 | 64.7 | 74.2 | 83.4 | |
| e | min | 71.3 | 82.6 | 93.56 | 104.86 | 6.58 | 23.36 | 29.56 | 37.29 | 45.2 | 55.37 | 66.44 | 76.95 | 88.25 | 99.21 | |
| m | max | 34 | 38 | 45 | 51 | 2.8 | 12.8 | 15.8 | 19.4 | 23.8 | 28.7 | 33.4 | 36 | 42 | 48 | |
| min | 32.4 | 36.4 | 43.4 | 49.1 | 2.55 | 12.1 | 15.1 | 18.1 | 22.5 | 27.4 | 31.8 | 34.4 | 40.4 | 46.4 | ||
| mw | min | 25.9 | 29.1 | 34.7 | 39.3 | 2 | 9.7 | 12.1 | 14.5 | 18 | 21.9 | 25.4 | 27.5 | 32.3 | 37.1 | |
| s | daqs=nominali massimu | 65 | 75 | 85 | 95 | 6 | 21 | 27 | 34 | 41 | 50 | 60 | 70 | 80 | 90 | |
| min | 63.1 | 73.1 | 82.8 | 92.8 | 5.82 | 20.67 | 26.16 | 33 | 40 | 49 | 58.8 | 68.1 | 78.1 | 87.8 | ||
DETTALJI TAL-PRODOTT
VANTAĠĠI TAL-PRODOTT
VANTAĠĠI TAL-Ġewż Hex Stainless Steel
1.Il-ġewż hex tal-istainless steel għandhom disinn mhux korrużiv u ħafif. Tista 'ssib proprjetajiet mekkaniċi tajbin fihom.
2.Jiżguraw ukoll rbit stabbli u jifilħu livell għoli ta 'temperatura tax-xogħol. M'hemm l-ebda kompromess fuq id-durabilità minħabba li dawn il-ġewż huma magħmula mill-istainless steel.
3.Stainless Steel Flat Hex Nuts huma qfieli versatili, li għandhom firxa ta 'applikazzjonijiet f'industriji differenti.
4.Huwa faċli li ddawwar dawn il-ġewż minħabba li għandhom 6 naħat.
5.F'AYA Fasteners, għandna l-aħjar tim biex iwassal il-ġewż fl-aħjar kundizzjoni.
6.Għandna l-ebda ħlasijiet moħbija, u tista 'tixtri dawn il-ġewż bl-aktar rati affordabbli.
SPEZZJONI TAL-KWALITÀ
PAKKETT U TAGĦBIJA TAL-KONTENITURI
XENARJI TA' UŻU
GĦALIEX AGĦŻEL AYA?
AYA tipprovdi servizzi esklussivi lil 1000 membru flimkien ma 'kull sena minn madwar id-dinja kollha, b'sistema unika ta' soluzzjoni ta 'servizz ta' katina, għandek bżonn biss li tikklikkja l-maws biex tikseb soluzzjoni esklussiva ta 'rbit u tgawdi servizzi bieb bieb.
